| 中文 | 英文（行业标准译法） |
| 英文翻译 |
| 设备型号 | Model | 1900-220 | Model: 1900-220 |
| 毛毯宽度 | Felt Width | 1920mm | Felt Width: 1920mm |
| 转印材料宽度 | Transfer Material Width | 1800mm | Transfer Material Width: 1800mm |
| 电压 | Voltage | 380V | Voltage: 380V |
| 转印速度 | Transfer Speed | 20-80米/每小时 | Transfer Speed: 20–80 m/h |
| 温度范围 | Temperature Range | 室温-250℃ | Temperature Range: Ambient ~ 250℃ |
| 收放系统 | Unwinding & Rewinding System | 3套 | Unwinding & Rewinding System: 3 sets |
| 加热辊筒直径 | Heated Roller Diameter | 220mm | Heated Roller Diameter: 220mm |
| 辊筒 | Roller | 特氟龙涂层 | Roller: Teflon coated |
| 毛毯偏出报警 | Felt Deviation Alarm | 选配 | Felt Deviation Alarm: Optional |
| 自动降温 | Automatic Cooling | 选配 | Automatic Cooling: Optional |
| 毛毯调整形式 | Felt Adjustment Mode | 手动调节 | Felt Adjustment Mode: Manual adjustment |
| 加热功率 | Heating Power | 10.2kw | Heating Power: 10.2 kW |
| 总功率 | Total Power | 11kw | Total Power: 11 kW |
| 加热方式 | Heating Method | 油导热 | Heating Method: Thermal oil circulation |
| 主机尺寸 | Main Machine Dimension | 长2750* | Main Machine Dimensions: L2750 × W2670 × H1390 mm |
| 宽2670* |
| 高1390mm |
| 平台尺寸 | Platform Dimension | 长2030* | Platform Dimensions:
L2030 × W2050 × H920 mm |
| 宽2050* |
| 高920mm |
| 机器总重量 | Total Machine Weight | 1000kg | Total Machine Weight: 1000 kg |
| 报价 RMB | Quotation (RMB) | 28000 | Quotation: RMB 28,000 |
